GEFFEN 8-inch Coaxial Ceiling Speaker

Cabinet Dimensions

280（W）*280（D）*190（H）MM ±1.5MM

Maximum Package Dimensions

345（W）-*345(D)*245(H) MM ±1.5MM

Cutout Size for Installation

φ 247mm

Cabinet Finish

Iron color on surface

Unit Configuration

8” coaxial speaker × 1

Speaker Type

8” coaxial speaker dedicated for public address & conference systems

DC Resistance

6.4Ω±15%

Nominal Impedance

8 OHM

Transformer Constant Voltage Power

15W/30W/60W@100V

Rated Input Power

50W

Maximum Input Power

80W

Frequency Response

60HZ~20KHZ

Sensitivity

90 dB

Quality Control Tolerance

±2dB(<1KHz)

Magnetic Shielding Test

Non-magnetic shielding

Shock & Drop Test

1m free fall from relative height, 6-sided drop, no product damage
