4K60 KVM Network Transmitter (100M)
GF-4KLD241 TP

Detail

Integrated Network Cable Transmitter

Maximum network cable length: 100 m; supports POC power supply with DC12V voltage

Supports bidirectional RS232 and IR data transmission; CEC is not supported

Supports reverse USB keyboard and mouse function: connect the TX terminal to the PC host and the RX terminal to keyboard and mouse devices (only keyboard and mouse HID devices are supported)

TX terminal: 1-channel HDMI input, 1-channel HDMI loop output, 1-channel analog audio output

RX terminal: 2-channel HDMI outputs, 1-channel analog audio output

Maximum supported video signal: 4K@60

EDID pass-through: when the HDMI loop output port of the TX terminal and the HDMI output port of the RX terminal are connected to display devices at the same time, EDID will be adjusted automatically and adopt the intersection of EDID combinations of each display device to ensure normal video output
