●Adopts a 64-bit Cortex-A53 MPCore ARM architecture quad-core 2.5GHz microprocessor.

★Equipped with 64G EMMC FLASH memory, expandable up to 256G.

★Supports multi-platform control, compatible with Android, iOS, Windows, HarmonyOS, Kylin, UOS and Linux-based operating systems.

★The host supports docking modes including one-screen multi-device, multi-screen one-device and multi-screen multi-device. It has 32 built-in independent Socket servers and can control up to 32 devices.

★Supports adding central control programming for multiple devices on the programming interface. Simply download the program to the host without any configuration operations on slave devices.

★Supports graphical logic programming and LUA language code programming, meeting the usage needs of different operators.

●Multiple communication protocols supported: RS-232, RS-422, RS-485, ModBus, TCP server/client, UDP, HTTP, PJLINK, Websocket. Zigbee and KNX communication are expandable.

●Supports computer WOL (Wake-on-LAN), remote shutdown, PPT control, system function calling, Unity3D application control and exhibition hall playback control.

★Built-in Huawei video terminal API interface; control can be easily implemented with a single function, with message callback supported.

●Features bidirectional communication; dynamic display of device status can be achieved through simple programming.

★Allows setting text boxes as reserved values in the editing interface to display date, time, day of the week, battery level and network connection status.

★Supports direct calling of system message prompt boxes and message selection boxes on the control interface, with reserved callback interfaces for user selection results, greatly simplifying the editing of powerful interface control effects.

★The control interface supports dynamic image design, easily achieving a top-tier and dazzling control experience.

★Supports virtual operation and real-time control of the interface during interface design.

●Has timeline and multi-thread event editing functions.

●Auto clock timing setting function; user-defined scheduled tasks can be executed accurately, with the scheduled actions set precisely to the year, month, day, hour, minute and second.

●Supports connection of environmental collectors and sensors such as temperature, humidity, photosensitive, PM2.5/PM10 sensors; commands can be automatically triggered according to personal usage habits and real-time external conditions.

●Enables central control information query and modification, infrared learning and testing, central control program downloading and firmware upgrading via network, eliminating the need for USB connection and facilitating more convenient management.

●Has one-click infrared testing function; during infrared learning, infrared data can be sent to all ports with one click, avoiding infrared control failure issues during later use.

★Built-in powerful timed lock function, preventing illegal cracking methods such as battery removal, and avoiding project payment arrears.

★Built-in buzzer that beeps once during startup.
