●Adopts an industrial-grade 32-bit dual-core ARM A7 high-performance processor with a maximum frequency of 800MHz, delivering stronger real-time processing capability.

●2Gbit NAND FLASH and 128MB DDR3 memory.

★ Provides 2 host interfaces, supporting connection to the upper host via DB9 female serial port or TCPServer connection mode, with the serial port supporting a maximum baud rate of 115200.

★ Equips with 16 serial ports with DB9 male connectors. Each port can be configured as RS232 or RS485 (the two modes are mutually exclusive), and supports bidirectional communication for connecting subordinate devices.

●Configurable serial port baud rates: 1200, 4800, 9600, 38400, 115200, etc., with a maximum support of 1M baud rate.

●Each data packet supports a maximum size of 247 bytes; packets exceeding this size will be discarded.

●Serial ports support 8 data bits, 1 or 2 stop bits, as well as odd parity, even parity or no parity.

●10/100M adaptive Ethernet interface.

●Supports static IP addressing.

●Supports web-based configuration with convenient and flexible parameter import and export functions.

●Features password protection for a high level of security.

●Equipped with Ethernet and serial port indicator lights for clear visualization of device operating status.

●Comes with a Reset button for system reset and restoration to factory settings in case of parameter configuration errors.

★ Integrates power consumption monitoring and temperature monitoring functions for real-time tracking of device operation status.

★ Provides a USB-C firmware upgrade interface for underlying host firmware updates.

★ Optional WIFI connectivity function.
